Ethernet Network Test Bench
Prototype
Product Description
The Ethernet Network Test Bench from Technica Engineering is a hardware test bench that is used by our engineers to validate the overall Ethernet communication between ECUs on a system test level with the goal to provide a deep test coverage using automated scripts. Focusing on different phases of the communication (lifecycle, statup – midphase – shutdown), its main objectives are to control the quality of the protocols implemented in the ECUs and detecting errors in the tracked communication already from an early phase of development.
This test bench includes our Capture Modules, which are the key hardware for capturing the traffic from the ECUs. Our ANDi Observer software is used for automated trace analysis tasks, as it allows to use test modules for integration testing. The Capture Modules allow to link the Bus ID and highly precise hardware timestamps, which are directly accessible from the header of messages. Packet counters help to identify missing or dropped packets from traces, while the temperature and voltage of the ECUs and Capture Modules can be checked simultaneously in periodically recurring meta data. Besides Automotive Ethernet, this test bench can log CAN, FlexRay and LIN busses within the same setup with the same concept, as all bus traffic is encapsulated via the TECMP protocol and provided to a test PC over an Ethernet uplink. The system provides periodically recurring information for test automation to solve debugging issues in traces. Further, our Ethernet Network Test Bench validates the OEM interface description at different phases (lifecycle) of the vehicle through the application of different tests for each phase. It can be used to test the SOME/IP and SOME/IP-SD protocols and OEM message database (FIBEX, ARXML). Further it can be used for diagnostics tests, UDP-NM tests, switch tests and further test scenarios related to the system testing of a network that includes Automotive Ethernet.
Technical data
FACTS
- Test PC (Linux-based)
- ANDi Ethernet Test Suite (software)
- Capture modules: CM CAN Combo, CM LIN Combo, CM 1000 High
- Individual connectors for OEM ECUs and Pinning plan
- Mobile test station on rollers
- Individual adaptations possible
FEATURES
- Testing of networks with automotive Ethernet components
- Focus on testing the provided OEM message databases (e.g. FIBEX, ARXML) and the communication behavior of the TCP/IP stack, especially for the SOME/IP and SOME/IP-SD protocols
- System tests like diagnostic tests for all ECUs, UDP-NM tests, switch tests
- Controlling the quality of the protocols of the participating ECUs at different maturity levels
- Detecting issues in the tracked communication
- Predefined automated tests
- Additional acquisition of packet counter data, voltage and temperature measurements for error detection
- OEM-specific interface description to various vehicle development phases through dedicated tests at each phase
Downloads
If you have any question or you are wishing to receive the User Manual or more information on Ethernet Network Test Bench, feel free to contact us at technicalsales@technica-engineering.de
